e-STUDIO3508LP/4508LP/5008LP
Toshiba's Hybrid MFP e-STUDIO5008LP series are monochrome MFPs with the world's first erasable print function which allows you to use the same paper over and over again.
Specifications
| Model | e-STUDIO3508LP | e-STUDIO4508LP | e-STUDIO5008LP | |
|---|---|---|---|---|
| General Feature | ||||
| Copy / Print Speed (ppm) | EB toner | 35 | 35 | 35 |
| Bk toner | 35 | 45 | 50 | |
| Warm-up Time (from low power mode) | Approx. 22 sec. | Approx. 26 sec. | Approx. 26 sec. | |
| Memory | 4 GB | |||
| Storage | 320GB Self-Encryption HDD | |||
| Dimension (W x D x H) | 585 x 640 x 787 mm / 23" x 25.2" x 31" *1 | |||
| Weight | Approx. 73 kg / 161 lb | |||
| Input Paper Capacity | Standard | 1,200 sheets (2 x 500 sheets*2, 100 sheets*3) | ||
| Maximum | 3,200 sheets | |||
| Available Paper Weight | 60 - 256 g/m² / 16 lb. Bond - 140 lb. Index *4 | |||
| Available Paper size | A5-R to A3 / ST-R to LD, non-standard size (~297 x 432 mm) | |||
| Document feeder | Optional 300-sheet DSDF or 100-sheet RADF | |||
| Duplexing | Standard | |||
| Finishing Option | Multi-Position stapling finisher, Saddle Stitching Finisher, Inner Finisher, Job Separator | |||
| Copier Feature | ||||
| First Copy Speed | EB toner | 7.8 sec. | 7.8 sec. | 7.8 sec. |
| Bk toner | 5.9 sec. | 4.4 sec. | 4.4 sec. | |
| Resolution | 600 x 600 dpi, 2,400 (equiv.) x 600 dpi with smoothing | |||
| Multiple Copy | Up to 999 | |||
| Printer Feature | ||||
| Resolution | 600 x 600 dpi, 5 bit, 1,200 x 1,200 dpi, 2 bit (equiv. 3,600 x 1,200 dpi) with PostScript driver |
|||
| Supported PDL | PCL5e, PCL5c, PCL6 (PCL XL), XPS and PostScript 3 compatible | |||
| Interface | Standard | USB (High speed), 10/100/1000BASE-T | ||
| Option | Wireless LAN (IEEE802.11 b/g/n), Bluetooth | |||
| Scanner Feature | ||||
| Resolution | 100/150/200/300/400/600dpi | |||
| Max. Scan Speed | DSDF | 240 spm (Duplex) / 120 spm (Simplex) (300 dpi) | ||
| RADF | 73 spm (300 dpi) | |||
| Data format | Standard | TIFF, PDF, XPS, JPEG, Compressed PDF, PDF/A, Encrypted PDF | ||
| Option | Searchable PDF, DOCX, EXLS, PPTX | |||
| Scan Protocol | SMB, FTP, IPX, FTPS | |||
| Scan features | File, Email, USB, e-Filing Box, TWAIN | |||
| Internet Fax | ITU-T T.37 (Simple mode) | |||
| Fax Feature (option) | ||||
| Communication mode / Modem Speed |
Super G3 / 33.6kbps | |||
| Data Compression | JBIG, MMR, MR, MH | |||
| Number of Lines (Std. / Max.) | 1 / 2 | |||
| Phonebook | 3,000 stations | |||
| Security Feature | ||||
| Standard | Self-encryption HDD with Wipe technology, TLS, Private Print, Encrypted print, Tracking Print, Encrypted PDF, User Authentication, Role Based Access Control, IP/MAC Address filtering, SNMPv3, 802.1X for Wired/Wireless, Fax secure receiving, Fax mis-sending prevention, Security event logging, Password Policy, Integrity Check | |||
| Optional | Card authentication, NFC authentication, Data Overwrite, IPsec, Hardcopy Security Printing, FIPS Certified Self-encryption HDD with Wipe technology | |||
*1 Depth is different depending on angle of the control panel.
*2 If drawer is used for reusable paper, paper capacity of drawer is max. 400 sheets.
*3 If bypass is used for reusable paper, paper capacity of bypass is max. 30 sheets.
*4 Paper weight for Erasable Blue mode: 64-80 g/m2 / 17-20lb. Bond.
*5 Specifications and options vary by region.
| Model | e-STUDIO RD301 (Paper Reusing Device) |
|---|---|
| General Feature | |
| Warm-up Time | Approx. 40 sec. |
| Available Paper size | A5-R to A4-R / ST-R to LT-R |
| Available Paper Weight | 64 - 80 g/m2 / 17 - 20lbs. Bond |
| Input Paper Capacity | 100 sheets |
| Dimension (W x D x H) | 470 x 470 x 825 mm / 18.5" x 18.5" x 32.5" |
| Weight | Approx. 45 kg / 99.2 lbs |
| Erasing Feature | |
| Erasing Speed (sheets/minute) | 30 |
| Special Features | Auto sorting into reusable and non-reusable |
| Scanner Feature | |
| Resolution | 100/150/200/300dpi |
| Max. Scan Speed (Color/B&W) | 15 spm (200 dpi) |
| Data format | TIFF, PDF, JPEG |
| Scan Protocol | SMB, WebDAV |
| Scan features | File, USB |
* Specifications and options vary by region.
