e-STUDIO image

e-STUDIO3508LP/4508LP/5008LP

Toshiba's Hybrid MFP e-STUDIO5008LP series are monochrome MFPs with the world's first erasable print function which allows you to use the same paper over and over again.

Specifications

Modele-STUDIO3508LPe-STUDIO4508LPe-STUDIO5008LP
General Feature
Copy / Print Speed (ppm) EB toner 35 35 35
Bk toner 35 45 50
Warm-up Time
(from low power mode)
Approx. 22 sec. Approx. 26 sec. Approx. 26 sec.
Memory 4 GB
Storage 320GB Self-Encryption HDD
Dimension (W x D x H) 585 x 640 x 787 mm / 23" x 25.2" x 31" *1
Weight Approx. 73 kg / 161 lb
Input Paper Capacity Standard 1,200 sheets (2 x 500 sheets*2, 100 sheets*3)
Maximum 3,200 sheets
Available Paper Weight 60 - 256 g/m² / 16 lb. Bond - 140 lb. Index *4
Available Paper size A5-R to A3 / ST-R to LD, non-standard size (~297 x 432 mm)
Document feeder Optional 300-sheet DSDF or 100-sheet RADF
Duplexing Standard
Finishing Option Multi-Position stapling finisher, Saddle Stitching Finisher, Inner Finisher, Job Separator
Copier Feature
First Copy Speed EB toner 7.8 sec. 7.8 sec. 7.8 sec.
Bk toner 5.9 sec. 4.4 sec. 4.4 sec.
Resolution 600 x 600 dpi, 2,400 (equiv.) x 600 dpi with smoothing
Multiple Copy Up to 999
Printer Feature
Resolution 600 x 600 dpi, 5 bit,
1,200 x 1,200 dpi, 2 bit (equiv. 3,600 x 1,200 dpi) with PostScript driver
Supported PDL PCL5e, PCL5c, PCL6 (PCL XL), XPS and PostScript 3 compatible
Interface Standard USB (High speed), 10/100/1000BASE-T
Option Wireless LAN (IEEE802.11 b/g/n), Bluetooth
Scanner Feature
Resolution 100/150/200/300/400/600dpi
Max. Scan Speed DSDF 240 spm (Duplex) / 120 spm (Simplex) (300 dpi)
RADF 73 spm (300 dpi)
Data format Standard TIFF, PDF, XPS, JPEG, Compressed PDF, PDF/A, Encrypted PDF
Option Searchable PDF, DOCX, EXLS, PPTX
Scan Protocol SMB, FTP, IPX, FTPS
Scan features File, Email, USB, e-Filing Box, TWAIN
Internet Fax ITU-T T.37 (Simple mode)
Fax Feature (option)
Communication mode
/ Modem Speed
Super G3 / 33.6kbps
Data Compression JBIG, MMR, MR, MH
Number of Lines (Std. / Max.) 1 / 2
Phonebook 3,000 stations
Security Feature
Standard Self-encryption HDD with Wipe technology, TLS, Private Print, Encrypted print, Tracking Print, Encrypted PDF, User Authentication, Role Based Access Control, IP/MAC Address filtering, SNMPv3, 802.1X for Wired/Wireless, Fax secure receiving, Fax mis-sending prevention, Security event logging, Password Policy, Integrity Check
Optional Card authentication, NFC authentication, Data Overwrite, IPsec, Hardcopy Security Printing, FIPS Certified Self-encryption HDD with Wipe technology

*1 Depth is different depending on angle of the control panel.
*2 If drawer is used for reusable paper, paper capacity of drawer is max. 400 sheets.
*3 If bypass is used for reusable paper, paper capacity of bypass is max. 30 sheets.
*4 Paper weight for Erasable Blue mode: 64-80 g/m2 / 17-20lb. Bond.
*5 Specifications and options vary by region.

Model e-STUDIO RD301 (Paper Reusing Device)
General Feature
Warm-up Time Approx. 40 sec.
Available Paper size A5-R to A4-R / ST-R to LT-R
Available Paper Weight 64 - 80 g/m2 / 17 - 20lbs. Bond
Input Paper Capacity 100 sheets
Dimension (W x D x H) 470 x 470 x 825 mm / 18.5" x 18.5" x 32.5"
Weight Approx. 45 kg / 99.2 lbs
Erasing Feature
Erasing Speed (sheets/minute) 30
Special Features Auto sorting into reusable and non-reusable
Scanner Feature
Resolution 100/150/200/300dpi
Max. Scan Speed (Color/B&W) 15 spm (200 dpi)
Data format TIFF, PDF, JPEG
Scan Protocol SMB, WebDAV
Scan features File, USB

* Specifications and options vary by region.
