TOSHIBA BV410D/BV420D Series



TOSHIBA BV400D series is an advanced entry printer with small footprint and compact & stylish body offering the operational convenience to the customers. The leading-edge printer series flexibly fits into a variety of workplaces and offers the enhanced connectivity with ease of integrating various network devices depending on the customer’s work environments. The excellent throughput and high-quality printing boost up the productivity with excellent cost performance.

Specifications

  BV410D-GS/BV420D-GS BV410D-TS/BV420D-TS
CHARACTERISTICS
Print Method Direct thermal
Dimensions 174mm x 218mm x 173 mm (6.85” x 8.59” x 6.81”)
Weight 2.0 kg (4.4lb)
User Interface BV410D 2LEDs. 3Keys. 128 x 64dpts Graphic LCD
BV420D 3LEDs. 2Keys
Operating Temp./Humidity 5 to 40°C (40°F to 104° F)
25% to 85% RH(no condensation)
Power Supply AC100 to 240V, 50/60 Hz(External AC adapter)
PRINT
Resolution 203 dpi (8-dot/min) 300 dpi (11.8-dot/min)
Print Speed (max) 177.8 mm/sec (7"/sec) 127 mm/sec (5"/sec)
Print Speed (peel-off) 1016 mm/sec (4"/sec)
Print Width (max.) 108 mm (4.25") 105.7 mm(4.16")
Print Length (max.) 997 mm (39.3”)
MEDIA
Alignment Centred
Media (backing paper) Width 25.4 mm to 118.0 mm (1.00" to 4.64")
Label Thickness 0.06 mm to 0.19 mm (0.0024" to 0.0074")
issue mode Batch, Strip (option),Cut (option)
Inner Media Roll Diameter 25.4 mm, 38.1 mm, 42 mm or 76.2 mm (1.0".1.5".1.65" or 3.0")
Optional External media stand 76.2(3.0")
Outer Media Roll Diameter φ127(5.0)
φ214(8.4) When the optional External media stand is used
SOFTWARE & CONNECTIVITY
Emulations ZPLⅡ, DPL, SBPL
Printer Driver Windows: 10/8/7 (32/64 bit), Windows Server 2012/Server 2008 (32/64 bit)
Standard Interface USB Hi-Speed
Ethernet interface (10BASE-T,100BASE-TX)
Option Interface Serial Interface(RS-232C)
Wireless LAN interface(IEEE802.11a/b/g/n)
Bluetooth interface (Ver2.1+EDR)
OPTIONS
  Cutter module White (BV214-F-QM-S, BV214-P-QM-S)/ Black (BV224-F-QM-S, BV224-P-QM-S),
Peel-off module White (BV914-H-QM-S)/Black (BV924-H-QM-S),
Ecternal module stand (BV904-PH-QM-S)/Wireless LAN kid (BV700-WLAN-QM-S),
Bluetooth Inteface kit (BV700-BLTH-QM-S),Serial RS-232C I/F board(BV700-RS-QM-S),
AC adapter cover White (BV914-ACD-QM-S)/Black (BV924-ACD-QM-S)
  • Brochure (PDF FILE)
  • Driver download
