e-STUDIO2020AC/2520AC

The e-STUDIO2020AC/2520AC comprises an A3/LD-size color MFP series that offers print speeds of 20/25 ppm. For group projects, for business and for those who need color print function, we are here to assist you. The series incorporates with industry-leading technology and innovations that are designed to help small groups of people stay connect and simple.

Specifications

Model e-STUDIO2020AC e-STUDIO2520AC
General Feature
Copy / Print Speed (ppm) Color 20 25
B & W 20 25
Warm-up Time After power-on Approx. 21 sec. (68F/ 20C)
From sleep mode 220 - 240V : Less than 13.1 sec. (68F/ 20C)
120V : Less than 15 sec. (68F/ 20C)
From low power mode 220 - 240V : Less than 13.1 sec. (68F/ 20C)
120V : Less than 15 sec. (68F/ 20C)
Memory Std. 4GB
(Main memory + Page memory)
Storage Std. 128 GB (SSD) (Shared for all imaging functions)/ Opt. 512 GB (SSD) or 320 GB (HDD)
Dimension (W × D × H)
(Height at original glass/Angle of control panel:90 degrees)
575 x 586 x 662 mm / 22.6" × 23.1" × 26.1"
Weight Approx. less than 56.7 kg / 125.0 lbs (Incl. Drum)
Input Paper Capacity Standard 350 sheets (250+100)
(20 lb & 80 gsm)
Maximum 2,900 sheets (20 lb & 80 gsm, w/Optional LCF)
Available Paper Weight
(via SFB)
60 - 209 g/m² / 16 lb. Bond - 110 lb. Index
Available Paper size
(via SFB)
100 × 148 to A3 / 100 x 148 mm to LD
Document feeder Optional 100-sheet RADF
Duplexing Standard
Finishing Option Saddle Stitching Finisher, Inner Finisher, Job Separator
Copier Feature
First Copy Time Color Less than 9.5 sec.
B & W Less than 7.1 sec.
Resolution Color 600 dpi x 600 dpi, 3bit
B & W 600 dpi x 600 dpi, 3bit *1
2,400dpi (Equivalence) x 600dpi (with smoothing) *2
*1 or *2 is selected by copy mode automatically. No selectable by user.
Gradation 256 steps
Multiple Copy Up to 999 Copies/ Ten key input
Printer Feature
Resolution All PDL: 600 dpi x 600 dpi, 3bit
PS only: 1,200dpi x 1,200dpi 2bit (1,200dpi x 2,400dpi)
PDL PCL5e/c, PCL6 (PCL XL), PS3, PDF, XPS, JPEG
Interface Standard 10/100/1000baseT, USB 2.0 High Speed USB
Option IEEE802.11b/g/n, Bluetooth
Scanner Feature
Resolution 100/150/200/300/400/600dpi
Scan Speed DSDF
RADF 73 ppm (100,150,200,300 dpi), 62 ppm (400 dpi), 50 ppm (600 dpi)
Data format
(Color)
Standard JPEG, TIFF-Multi/Single Page, PDF-Multi/Single Page, Slim PDF-Multi/Single Page, XPS-Multi/Single Page
Option DOCX-Multi/Single Page, XLSX-Multi/Single Page, PPTX-Multi/Single Page
Scan features Scan to File, Scan to E-mail, Scan to e-Filing, Scan to WS Scan, Scan to USB, Scan Preview
Fax Feature (option)
Communication mode / Modem Speed Super G3, G3 / 33.6 kbps- 2.4 kbps (automatic fallback)
Data Compression JBIG, MMR, MR, MH
Number of Lines (Std. / Max.) 1/2
Phonebook 3,000 stations
Security Feature
Standard TPM 2.0, Anti-malware, Secure Boot, Self-Encrypting SSD, Private Print, Encrypted/digitally Signed PDF, User Authentication, Role Based Access Control, IP/MAC address filtering, TLS, Data Overwrite, 802.1X, SMBv3, Password policy, SNMPv3, Confidentiality setting, Tampering Prevention of Firmware, Hardcopy Security Printing, SCEP
Optional IPsec, FIPS certified Self-Encrypting HDD with Wipe Function, User Authentication (IC Card, Fingerprint, NFC, Multi-factor etc.), Trackable Hardcopy Security Printing




*This service is not available under this name, e-BRIDGE SKY SuiteTM, in the European region.
