TOSHIBA BA400 Series

BA400 Series The TOSHIBA BA400 barcode label printer provides the functionality and robustness of an industrial printer with the compact footprint and ease of use of a desktop printer.For ultimate networking capabilities, it comes with a wide variety of communication interfaces, enabling you to manage your whole network of printers from a central source.

Features

  • Keeping the good – field-proved & reliable hardware
  • New system platform with advanced connectivity
  • Superior features with future-orientated upgrade possibilities
    - New system platform and processor technology level up efficiency and productivity
    - Print language emulation ensures vast compatibility and easy integration into complex IT systems
    - Dual Band Wi-Fi (2.4GHz/5GHz) for improved wireless network connection quality
    - NFC pairing for on-demand connections via Bluetooth
    - Front-loading feature ensures smooth drop-in media loading
  • Enhanced productivity
  • Future-ready operating system
  • UHF RFID Kit (Availability varies from country to country)
  • Mobility & connectivity

Specifications

Models BA410T-GS12-QM-S BA410T-TS12-QM-S BA420T-GS12-QM-S BA420T-TS12-QM-S
Technology Thermal Transfer / Direct Thermal
Resolution 8 dots/mm (203 dpi) 11.8 dots/mm (300 dpi) 8 dots/mm (203 dpi) 11.8 dots/mm (300 dpi)
Print Speed 50.8 mm/sec. (2 inches/sec.), 101.6 mm/sec (4 inches/sec.), 152.4 mm/sec (6 inches/sec.), 203.2 mm/sec (8 inches/sec)
Interface USB interface (V2.0 High speed)
LAN interface (10/100BASE)
Bluetooth interface(2400MHz ~ 2483.5MHz , CLASS2(2.5mW))
NFC(MIFARE (ISO/IEC 14443 TypeA))
USB Host Interface
Barcodes JAN8, JAN13, EAN8, EAN8+2 digits, EAN8+5 digits, EAN13, EAN13+2 digits, EAN13+5 digits, UPC-E, UPC-E+2 digits, UPC-E+5 digits, UPC-A, UPC-A+2 digits, UPC-A+5 digits, MSI, ITF, NW-7, CODE39, CODE93, CODE128, EAN128, Industrial 2 to 5, Customer Bar Code, POSTNET, KIX CODE, RM4SCC (ROYAL MAIL 4STATE CUSTOMER CODE), GS1 DataBar, MATRIX 2 of 5 for NEC
2D Codes Data Matrix, PDF417, QR code, Maxi Code, Micro PDF417, CP Code, Security QR code, Aztec, GS1 Data Matrix
Fonts Times Roman (6 sizes), Helvetica (6 sizes), Presentation (1 size), Letter Gothic (1 size), Prestige Elite (2 sizes), Courier (2 sizes), OCR (2 types), Gothic (1 size), Outline font (4 types), Price font (3 types)
Optional Cutter module (BA204-QM-S)
Strip module (BA904-H-QM-S)
Cutter module (BA204P-QM-S)
Strip module (BA904P-H-QM-S)
Serial Interface Board (BA700-RS-QM-S)
Wireless LAN Board (BA700-WLAN-QM-S)
Expansion I/O Board (BA700-IO-QM-S)
Real Time Clock (BA700-RTC-QM-S)
Fan Fold Guide (BA904-FF-QM-S)
Parallel Interface (BA700-CEN-QM-S)
UHF RFID Module (BA704-RFID-U4-KR-S, BA704-RFID-U4-EU-S, BA704-RFID-U4-AU-S)
Dimensions 245 mm×414 mm×333 mm
(9.6"×16.3"×13.1")
245 mm×350 mm×332 mm
(9.6"×13.7"×13.1")
Weight 37.5 lb (15 kg) (Media and ribbon are not.) 26.5 lb (12 kg) (Media and ribbon are not included.)
