TOSHIBA B-FP Series
Print labels, receipts and tags wherever and whenever you need. Our mobile printers come in handy when your job requires you to move around. In today’s fast moving world it is important to be able to react fast. All our printers were designed to operate in the most diverse working environments. They are robust and durable yet lightweight and easy to use.
Specifications
| B-FP2D | B-FP3D-GS (For Europe only) |
B-FP3D-GH | |
|---|---|---|---|
| CHARACTERISTICS | |||
| Technology | Direct thermal | ||
| Dimensions (excluding projecting parts) | 97 x 130 x 69 mm (W x D x H) |
116 x 150 x 80 mm (W x D x H) |
116 x 150 x 80 mm (W x D x H) |
| Weight | GH30: 460 g (with Battery) GH50: 467 g (with Battery) |
GS32: 630 g (with Battery) GS42: 640 g (with Battery) |
660 g (with Battery) |
| User interface | 128 x 128 pixel Graphic Colour Display 2 x LED (colours: blue, orange, red), 3 x key |
128 x 128 pixel Graphic Colour Display 2 x LED (colours: green, amber, red), 3 x key |
|
| Operating temperature | -15°C - 50°C (5°F - 122°F) | ||
| Power supply | Lithium ion 7.2V, 2500 mAh | ||
| Memory | 128 MB (FROM), 32 MB (SRAM) | 64 MB (FROM), 32 MB (SRAM) | 64 MB (FROM), 32 MB (SRAM) |
| Resolution | 203 dpi (8 dots/mm) | ||
| Max. print speed | 152 mm/second (6 ips) | 152 mm/second (6 ips) | 152 mm/second (6 ips) |
| Print Mode | Batch, Peel-off | Batch | Batch, Peel-off |
| Print type | Receipt, Tag, Label | Receipt, Tag, Label | Receipt, Tag, Label |
| MEDIA | |||
| Paper width | 54 mm | 72 mm | |
| Media roll size (OD) | 60 mm | 68 mm | |
| INTERFACE | |||
| USB 2.0 Full Speed (connector: USB-Type C) Bluetooth v2.1+EDR Wireless LAN (802.11a/b/g/n) NFC (for Bluetooth pairing) |
USB 2.0 Full Speed, Bluetooth v2.1+EDR, v4.0 BLE Dual or Wireless LAN (802.11 b/g/n) |
USB 2.0 Full Speed, Bluetooth v2.1+EDR, v4.0 BLE Dual or Wireless LAN (802.11 a/b/g/n) |
|
| OPTIONS | |||
| 1-slot battery charger, 6-slot battery charger, AC adapter, 1-slot cradle charger, 4-slot cradle charger, Shoulder strap, Spare battery pack, Linerless Platen Kit, Carry Case, DC jack plug adapter |
1-slot battery charger, 6-slot battery charger AC adapter, Cigarette lighter adapter, DC Jack plug adapter, Spare Battery, Shoulder strap |
1-slot battery charger, 6-slot battery charger, AC adapter, Cigarette lighter adapter, DC Jack plug adapter, Spare Battery, Shoulder strap |
|
| SOFTWARE & CONNECTIVITY | |||
| Printer Drivers | Windows 11/10/8.1, Windows Server 2019/2016/2012 R2/2012, SAP, OPOS, JPOS |
||
| Language mode | TPCL, ESC/POS, Basic Command Interpreter | ||
| Emulation | ZPL II, CPCL, SBPL | ZPL II, CPCL | |
| SDK | iOS, Android, Windows CE, Java, .NET | iOS, Android, Windows CE | |
| IoT Device Management | SOTI Connect (GH50 model only) | Not Available | SOTI Connect (GH52 model only) |
