e-STUDIO330AC/400AC

Seal_e-STUDIO400AC Seal_e-STUDIO330AC

With the common platform "e-BRIDGE" offering seamless office environment, e-STUDIO330AC/400AC have the same function and operability with all other e-STUDIO series. This enables users to use them without sense of incongruity. The high-precision compact MFPs are available for the combination use with A3 MFPs, because they can be directly placed in small meeting rooms, limited spaces, or even on the desks.

Specifications

Model e-STUDIO330AC e-STUDIO400AC
General Feature
Copy / Print Speed (ppm) Color 33/35 (A4/LT) 40/42 (A4/LT)
B & W 33/35 (A4/LT) 40/42 (A4/LT)
Warm-up Time Approx. 20 sec.
Memory Std. 4 GB/ Expandability: No
Storage 320GB
Dimension (W × D × H) 520 × 540* × 634 mm
Weight Less than 53 kg
Input Paper Capacity Standard 650 sheets
Maximum 3,200 sheets
Available Paper Weight 52-256 g/m² / 14 lb. Bond - 140 lb. Index
Available Paper size 98mm × 148mm to A4 / 98mm × 148mm to LG
Document feeder Standard 100-sheet DSDF
Copier Feature
First Copy Speed Color Less than 7.2 sec. Less than 6.3 sec.
B & W Less than 5.7 sec Less than 5.1 sec.
Resolution 600 x 600 dpi, 3bit*1
2,400dpi(Equivalence) x 600dpi (with smoothing) *2
*1 or *2 is selected by copy mode automatically. No selectable by user.
Multiple Copy Up to 999
Printer Feature
Resolution 600 x 600 dpi, 3bit
PDL PCL6 Emulation, PS3 Emulation, XPS
Interface Standard 10/100/1000 base T (Std.), USB 2.0 High Speed
Option IEEE802.11b/g/n, Bluetooth
Scanner Feature
Resolution 100/150/200/300/400/600 dpi
Max. Scan Speed
For A4:
Color: Up to 80 spm (Duplex)/
Up to 40 spm (Simplex) (300dpi)
For LT:
Color: Up to 82 spm (Duplex)/
Up to 41 spm (Simplex) (300dpi)
B & W: Up to 116 spm (Duplex)/
Up to 58 spm (Simplex) (300dpi)
B & W: Up to 120 spm (Duplex)/
Up to 60 spm (Simplex) (300dpi)
Data format B&W: TIFF, PDF, XPS Gray Scale: JPEG, TIFF, PDF, Slim PDF, XPS
Full Color: JPEG, TIFF, PDF, Slim PDF, XPS
Auto Color (ACS): TIFF, PDF, XPS
*TIFF file in ACS mode is Single-page only. Others are all supporting both Multi-page and Single-page.
Scan Protocol SMB, FTP, IPX/SPX, FTPS, USB, Netware
Scan features Scan to File, Scan to Email, Scan to e-Filling, Scan to USB, Scan to WS scan
Internet Fax ITU-T T.37 (Simple mode)
Fax Feature (option)
Communication mode / Modem Speed Super G3 / 33.6kbps - 2.4 kbps
Data Compression JBIG, MMR, MR, MH
Number of Lines (Std. / Max.) 1
Phonebook 3,000 stations
Security Feature
Standard Self-encryption HDD with Wipe technology, TLS, Private Print, Encrypted print, Tracking Print, Encrypted PDF, User Authentication, Role Based Access Control, IP/MAC Address filtering, SNMPv3, 802.1X for Wired/Wireless, Fax secure receiving, Fax mis-sending prevention, Security event logging, Password Policy, Integrity Check, HCD-PP
Optional Card authentication, NFC authentication, Data Overwrite, IPsec, Hardcopy Security Printing, FIPS Certified Self-encryption HDD with Wipe technology

* Depth is changeable by an angle of control panel
**Specifications, and availability of models and options vary by region.
