e-STUDIO330AC/400AC
With the common platform "e-BRIDGE" offering seamless office environment, e-STUDIO330AC/400AC have the same function and operability with all other e-STUDIO series. This enables users to use them without sense of incongruity. The high-precision compact MFPs are available for the combination use with A3 MFPs, because they can be directly placed in small meeting rooms, limited spaces, or even on the desks.
Specifications
Model | e-STUDIO330AC | e-STUDIO400AC | |||
---|---|---|---|---|---|
General Feature | |||||
Copy / Print Speed (ppm) | Color | 33/35 (A4/LT) | 40/42 (A4/LT) | ||
B & W | 33/35 (A4/LT) | 40/42 (A4/LT) | |||
Warm-up Time | Approx. 20 sec. | ||||
Memory | Std. 4 GB/ Expandability: No | ||||
Storage | 320GB | ||||
Dimension (W × D × H) | 520 × 540* × 634 mm | ||||
Weight | Less than 53 kg | ||||
Input Paper Capacity | Standard | 650 sheets | |||
Maximum | 3,200 sheets | ||||
Available Paper Weight | 52-256 g/m² / 14 lb. Bond - 140 lb. Index | ||||
Available Paper size | 98mm × 148mm to A4 / 98mm × 148mm to LG | ||||
Document feeder | Standard 100-sheet DSDF | ||||
Copier Feature | |||||
First Copy Speed | Color | Less than 7.2 sec. | Less than 6.3 sec. | ||
B & W | Less than 5.7 sec | Less than 5.1 sec. | |||
Resolution | 600 × 600 dpi | ||||
Multiple Copy | Up to 999 | ||||
Printer Feature | |||||
Resolution | 600dpi ×600dpi 1,200dpi ×1,200dpi |
||||
PDL | PCL6 Emulation, PS3 Emulation, XPS | ||||
Interface | Standard | 10/100/1000 base T (Std.), USB 2.0 High Speed | |||
Option | IEEE802.11b/g/n, Bluetooth | ||||
Scanner Feature | |||||
Resolution | 100/150/200/300/400/600 dpi | ||||
Max. Scan Speed |
|
||||
|
|||||
Data format | B&W: TIFF, PDF, XPS Gray Scale: JPEG, TIFF, PDF, Slim PDF, XPS Full Color: JPEG, TIFF, PDF, Slim PDF, XPS Auto Color (ACS): TIFF, PDF, XPS *TIFF file in ACS mode is Single-page only. Others are all supporting both Multi-page and Single-page. |
||||
Scan Protocol | SMB, FTP, IPX/SPX, FTPS, USB, Netware | ||||
Scan features | Scan to File, Scan to Email, Scan to e-Filling, Scan to USB, Scan to WS scan | ||||
Internet Fax | ITU-T T.37 (Simple mode) | ||||
Fax Feature (option) | |||||
Communication mode / Modem Speed | Super G3 / 33.6kbps - 2.4 kbps | ||||
Data Compression | JBIG, MMR, MR, MH | ||||
Number of Lines (Std. / Max.) | 1 | ||||
Phonebook | 3,000 stations | ||||
Security Feature | |||||
Standard | Self-encryption HDD with Wipe technology, TLS, Private Print, Encrypted print, Tracking Print, Encrypted PDF, User Authentication, Role Based Access Control, IP/MAC Address filtering, SNMPv3, 802.1X for Wired/Wireless, Fax secure receiving, Fax mis-sending prevention, Security event logging, Password Policy, Integrity Check, HCD-PP | ||||
Optional | Card authentication, NFC authentication, Data Overwrite, IPsec, Hardcopy Security Printing, FIPS Certified Self-encryption HDD with Wipe technology |
* Depth is changeable by an angle of control panel
**Specifications, and availability of models and options vary by region.
*This service is not available under this name, e-BRIDGE SKY SuiteTM, in the European region.
