TOSHIBA B-EX6T

B-EX6TThe Toshiba B-EX6 series - redefining the Industrial printer marketplace. Combining market leading technology with usability, reliability and the lowest total cost of ownership. Extending the capabilities of our existing range of B-EX printers to cover the most demanding applications, for heavy duty industrial printing.  Rugged and durable design, advanced functionality, cost saving features and a wide choice of models and options for the best “all-in-one” industrial solution.

Features

Cost of Ownership

Performance and functionality to meet the demands of the wide-web printing marketplace, designed with features and options to offer the lowest cost of ownership; including an extended long-life print head; Toshiba’s unique ribbon save mode and an 800m ribbon, to improve efficiencies and ultimately reduce costs over the life of the printer.

Flexible Design

The B-EX6 has been designed with the same durability and reliability as the B-EX4 range, with rugged and robust outer casing. But we have added more: a bi-cover to reduce footprint and opening space and essential operator usability, for ease of operation, reduced maintenance costs and minimal down-time.

Improve your efficiency

Supporting 6 inch media, with speeds of up to 12 inches per second, the B-EX6 range can handle the most demanding printing applications. In addition, high throughput is facilitated with advanced processing capabilities, increasing overall efficiency and productivity.

Enhanced connectivity

For flexible connectivity options, USB and Ethernet come as standard on the B-EX6 series. The optional Bluetooth functionality allows for parameter settings directly from your smart phone or mobile device.

Range of Models

A choice of models to suit any application, with 200 and 300 dpi variants for superior print quality and perfect readability of barcodes. Flat head and near edge head models enable easy replacement of legacy printer estates, and a wide range of media and options offer flexibility for any printing application.

Application

  • Industry & Manufacturing
    - Automotive, Chemical, Pharmaceutical, Textile, Electronics, Food & Beverages
  • Government
    -Utilities
  • Retail Distribution
  • Transport and Logistics
  • Healthcare
  • Telecommunications



Specifications

  B-EX6T1-GS/TS12 B-EX6T3-GS/TS12
CHARACTERISTICS
Printhead Near-edge head Near-edge head with cool down bar
Dimensions 331 (W) x 480 (D) x 310 (H) mm
Weight 20 kg
User interface Graphic LCD, 2 x LED, 10 x key
Operating Temperature 5°C to 40°C / 25-85% non-condensing
Standard Interface USB 2.0, LAN 10/100 Base, IPv6, USB Host/RTC,
Optional Interface RS232, Centronics, Wireless LAN, EX I/O
Memory System (Flash Memory) 64MB, SRAM 32MB
Power Supply AC 100 to 240V, 50/60 Hz
PRINT
Method Direct thermal / Thermal transfer
Resolution 203/305 dpi ( 8/12 dots/mm)
Maximum Print Width 160mm
Maximum Print Length 1490mm
Maximum Print Speed 305 mm/second (12 ips)
Ribbon Save Function Yes No
Barcodes UPC/EAN/JAN, Code 39, Code 93, Code 128, EAN 128, NW7, MSI, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Postnet, RM4SCC, KIX-Code, Customer Barcode, GS1 Databar
2D Codes Data Matrix, PDF 417, Maxicode, QR Code, Micro PDF 417, CP Code
Font Bitmap font, Outline font, Price font, TTF, OFT
RIBBON
Type of ribbon Edge head type Flat head type
Maximum Ribbon Width 170mm
Maximum Ribbon Length 800 m (Up to 5 inch width) 600 m
MEDIA
Paper Alignment Center
Backing Paper Width 50-165 mm
Label Thickness 0.13-0.17 mm
Tag Thickness 0.08-0.25mm
Paper Roll 200 mm (7.9")
SOFTWARE & CONNECTIVITY
Printer Driver Windows 10/8/7/Vista (32/64 bit)
Windows Server 2012/Server 2008 (32/64 bit)
Language Mode TPCL, ZPL II, BCI (function)
OPTIONS
  Disc cutter, Peel-off module, Fan fold guide, RS232, Centronics, Wireless LAN, EX I/O, RFID Kit*

(*) For T1 model only
