e-STUDIO5518A/6518A/7518A/8518A
The e-STUDIO5518A/6518A/7518A/8518A are high-end monochrome MFPs that boast printing output 55/65/75/85 ppm. This series features enhanced user interface, advanced cloud and mobile printing capabilities. Those functions enable those of you who need to copy and scan large amounts of monochrome documents with high speed and high volumes. Such advanced functions will help you improve your daily work.
Specifications
| Model | e-STUDIO5518A | e-STUDIO6518A | e-STUDIO7518A | e-STUDIO8518AC | |
|---|---|---|---|---|---|
| General Feature | |||||
| Copy / Print Speed (ppm) | 55 | 65 | 75 | 85 | |
| Warm-up Time | Approx. 24 sec. | Approx. 20 sec. | |||
| Memory | 4 GB | ||||
| Storage | 320GB Self-Encryption HDD | ||||
| Dimension (W × D × H) | 955 × 698* × 1,227 mm / 37.6" × 27.5"* × 47.7" | ||||
| Weight | Approx. 195 kg / 430 lb | ||||
| Input Paper Capacity | Standard | 3,520 sheets | |||
| Maximum | LCF 6,020 sheets/ 4- Drawer model: 4,780 sheets | ||||
| Available Paper Weight | 60 - 300 g/m² / 16 lb. Bond - 110lb. Cover | ||||
| Available Paper size | 100 × 148 to 330 x 483mm / 100 × 148 to 13" x 19", Banner paper (1,200 mm) | ||||
| Document feeder | Standard 300-sheet DSDF | ||||
| Duplexing | Standard | ||||
| Finishing Option | Multi-Position stapling finisher,Saddle Stitching Finisher | ||||
| Copier Feature | |||||
| First Copy Speed | 5.2 sec. | 4.5 sec. | 4.1 sec. | ||
| Resolution | 2,400 × 600 dpi (with smoothing) | ||||
| Multiple Copy | Up to 9999 | ||||
| Printer Feature | |||||
| Resolution | 600 × 600 dpi, 2,400 × 600 dpi (with soothing), 1,200 × 1,200 (PS only), 3,600 × 600 dpi (with soothing/PS only) | ||||
| PDL | PCL6 Emulation, PS3 Emulation, XPS | ||||
| Interface | Standard | USB (High speed), 10/100/1000BASE-T | |||
| Option | Wireless LAN (IEEE802.11 b/g/n), Bluetooth | ||||
| Scanner Feature | |||||
| Resolution | 100/150/200/300/400/600dpi | ||||
| Scan Speed | Up to 240 spm (Duplex) / Up to 120 spm (Simplex) (300 dpi) | ||||
| Data format | Standard | TIFF, PDF, XPS, JPEG, Slim PDF, PDF/A | |||
| Option | DOCX, EXLS, PPTX, Searchable PDF | ||||
| Scan Protocol | SMB, FTP, IPX/SPX, FTPS, USB, Netware | ||||
| Scan features | File, Email, USB, e-Filing Box, TWAIN, Local HDD, Share Point, iFax, Fax, WS Scan | ||||
| Internet Fax | ITU-T T.37 (Simple mode) | ||||
| Fax Feature (option) | |||||
| Communication mode / Modem Speed | Super G3 / 33.6kbps - 2.4 kbps | ||||
| Data Compression | JBIG, MMR, MR, MH | ||||
| Number of Lines (Std. / Max.) | 1 / 2 | ||||
| Phonebook | 3,000 stations | ||||
| Security Feature | |||||
| Standard | Self-encryption HDD with Wipe technology, TLS, Private Print, Encrypted print, Tracking Print, Encrypted PDF, User Authentication, Role Based Access Control, IP/MAC Address filtering, SNMPv3, 802.1X for Wired/Wireless, Fax secure receiving, Fax mis-sending prevention, Security event logging, Password Policy, Integrity Check, HCD-PP | ||||
| Optional | Card authentication, NFC authentication, Data Overwrite, IPsec, Hardcopy Security Printing, FIPS Certified Self-encryption HDD with Wipe technology | ||||
* Depth is different depending on angle of the control panel.
**Specifications, and availability of models and options vary by region.
*This service is not available under this name, e-BRIDGE SKY SuiteTM, in the European region.
