The e-STUDIO5516AC/6516AC/7516AC are high-end color MFPs that boast a color printing output 55/65/75 ppm. Many amounts of printings and scanning are required for daily work? If yes, here we have some solutions for you. This series of MFPs integrates newly-engineered software, enhanced user interface, and embedded application platform. Such advanced functions are your best business partners in your daily work.


Model e-STUDIO5516AC e-STUDIO6516AC e-STUDIO7516AC
General Feature
Copy / Print Speed (ppm) Color 55 65 75
B & W 65 75 85
Warm-up Time Approx. 20 sec.
Memory 4 GB
Storage 320GB Self-Encryption HDD
Dimension (W × D × H) 955 × 698* × 1,227 mm / 37.6" × 27.5"* × 47.7"
Weight LCF model: 213 kg / 469 lb, 4-drawer model: 212 kg / 467 lb
Input Paper Capacity Standard LCF model: 3,520 sheets, 4-drawer model: 2,280 sheets
Maximum LCF model: 6,020 sheets, 4-drawer model: 4,780 sheets
Available Paper Weight 60 - 300 g/m² / 16 lb. Bond - 110lb. Cover
Available Paper size 100 x 148 to 330 x 483mm / 100 x 148 to 13"x19", Banner paper (1,200 mm)
Document feeder Standard 300-sheet DSDF
Finishing Option Multi-Position stapling finisher,Saddle Stitching Finisher
Copier Feature
First Copy Speed Color 6.4 sec. 6.4 sec. 5.4 sec.
B & W 5.2 sec. 4.5 sec. 4.1 sec.
Resolution 600 × 600 dpi 2400 dpi × 600 dpi
Multiple Copy Up to 9999
Printer Feature
Resolution 600dpi x 600dpi 5bit*1 2400dpi (Equivalence) x 600dpi (with smoothing)
*2 *1 or *2 is selected by copy mode automatically. No selectable by user.
PDL PCL6 Emulation, PS3 Emulation, XPS
Interface Standard USB (High speed), 10/100/1000BASE-T
Option Wireless LAN (IEEE802.11 b/g/n), Bluetooth
Scanner Feature
Resolution 100/150/200/300/400/600dpi
Scan Speed Up to 240 spm (Duplex) / Up to 120 spm (Simplex) (300 dpi)
Data format Standard TIFF, PDF, XPS, JPEG, Slim PDF, PDF/A
Option DOCX, EXLS, PPTX, Searchable PDF
Scan Protocol SMB, FTP, IPX/SPX, FTPS, USB, Netware
Scan features File, Email, USB, e-Filing Box, TWAIN, Local HDD, Share Point, iFax, Fax, WS Scan
Internet Fax ITU-T T.37 (Simple mode)
Fax Feature (option)
Communication mode / Modem Speed Super G3 / 33.6 kbps- 2.4 kbps
Data Compression JBIG, MMR, MR, MH
Number of Lines (Std. / Max.) 1 / 2
Phonebook 3,000 stations
Security Feature
Standard Self-encryption HDD with Wipe technology, TLS, Private Print, Encrypted print, Tracking Print, Encrypted PDF, User Authentication, Role Based Access Control, IP/MAC Address filtering, SNMPv3, 802.1X for Wired/Wireless, Fax secure receiving, Fax mis-sending prevention, Security event logging, Password Policy, Integrity Check, HCD-PP
Optional Card authentication, NFC authentication, Data Overwrite, IPsec, Hardcopy Security Printing, FIPS Certified Self-encryption HDD with Wipe technology

* Depth is different depending on angle of the control panel.
**Specifications, and availability of models and options vary by region.




*This service is not available under this name, e-BRIDGE SKY SuiteTM, in the European region.
