TOSHIBA B-FP Series



Print labels, receipts and tags wherever and whenever you need. Our mobile printers come in handy when your job requires you to move around. In today’s fast moving world it is important to be able to react fast. All our printers were designed to operate in the most diverse working environments. They are robust and durable yet lightweight and easy to use.

Specifications



B-FP2D

B-FP3D-GS

B-FP3D-GH

CHARACTERISTICS
Technology Direct thermal
Dimensions (excluding projecting parts) 97 x 130 x 69 mm
(W x D x H)
116 x 150 x 80 mm
(W x D x H)
116 x 150 x 80 mm
(W x D x H)
Weight GH30: 460 g (with Battery)
GH50: 467 g (with Battery)
650 g (with Battery) 660 g (with Battery)
User interface 128 x 128 pixel Graphic Colour Display
2 x LED (colours: blue, orange, red), 3 x key
128 x 128 pixel Graphic Colour Display
2 x LED (colours: green, amber, red), 3 x key
Operating temperature -15°C - 50°C (5°F - 122°F)
Power supply Lithium ion 7.4V, 2500 mAh
Memory 128 MB (FROM), 32 MB (SRAM) 64 MB (FROM), 16 MB (SRAM) 64 MB (FROM), 32 MB (SRAM)
PRINT
Resolution 203 dpi (8 dots/mm)
Max. print speed 152 mm/second (6 ips) 105 mm/second (4.13 ips) 152 mm/second (6 ips)
Print Mode Batch, Peel-off Batch Batch, Peel-off
Print type Receipt, Tag, Label Receipt, Tag, Label Receipt, Tag, Label
MEDIA
Paper width 54 mm 72 mm
Media roll size (OD) 60 mm 68 mm
INTERFACE
  USB 2.0 Full Speed (connector: USB-Type C)
Bluetooth v2.1+EDR
Wireless LAN (802.11a/b/g/n)
NFC (for Bluetooth pairing)
USB 2.0 Full Speed,
Bluetooth v2.1+EDR,
v4.0 BLE Dual or Wireless LAN (802.11 b/g/n)
USB 2.0 Full Speed,
Bluetooth v2.1+EDR,
v4.0 BLE Dual or Wireless LAN (802.11 a/b/g/n)
OPTIONS
  1-slot battery charger, 6-slot battery charger,
AC adapter, 1-slot cradle charger,
4-slot cradle charger, Shoulder strap,
Spare battery pack, Linerless Platen Kit,
Carry Case, DC jack plug adapter
1-slot battery charger, 6-slot battery charger
AC adapter, Cigarette lighter adapter,
DC Jack plug adapter, Spare Battery,
Shoulder strap
1-slot battery charger, 6-slot battery charger,
AC adapter, Cigarette lighter adapter,
DC Jack plug adapter, Spare Battery,
Shoulder strap
SOFTWARE & CONNECTIVITY
Printer Drivers Windows 10/8/7 (32/64 bit),
Windows Server 2012/Server 2008 (32/64 bit), OPOS, JPOS
Language mode TPCL, ESC/POS, Basic Command Interpreter
Emulation ZPL II, CPCL, SBPL ZPL II, CPCL
SDK iOS, Android, Windows CE, Java, .NET iOS, Android, Windows CE
IoT Device Management SOTI Connect (GH50 model only) Not Available SOTI Connect (GH52 model only)
