TOSHIBA B-EX4D2/B-EX4T2

Specifications


B-EX4D2 B-EX4T2-GS/TS B-EX4T2-HS
CHARACTERISTICS
Print head Flat-type
Dimensions 278 x 460 x 310 mm (W x D x H)
Weight 17 kg
Interface USB 2.0, Ethernet
Optional Interface Serial interface, Parallel interface, Expansion I/O interface, RTC & USB Host interface, Wireless LAN interface
Network Tool SNMP
Memory 16 MB (FROM), 32 MB (SRAM)
PRINT
Method Direct thermal Direct thermal / Thermal transfer
Print Width 104 mm (4.09")
Max. Print Speed 304.8 mm/sec (12 ips) 152.8 mm/sec (6 ips)
Resolution 203 dpi 203 dpi / 300 dpi 600 dpi
Font Bitmap, Outline, Writable characters, Optional True Type
Barcode UPC/EAN/JAN, Code 39, Code 93, Code 128, EAN 128, NW7, MSI, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Postnet, RM4SCC, KIX-Code, Customer Barcode, GS1 Databar
2D Codes Data Matrix, PDF417, QR code, Maxi Code, Micro PDF417, CP Code
MEDIA
Paper Width 25 mm - 114 mm

15 mm – 114 mm

Paper Alignment Left
Paper Roll 200 mm (7.9")
RIBBON
Type of ribbon - Spool type
Maximum Ribbon Width - 112 mm
Maximum Ribbon Length - 600 mm
SOFTWARE & CONNECTIVITY
Printer Driver Windows 10/8/7 (32/64 bit), Windows Server 2012/Server 2008 (32/64 bit)
Language Mode TPCL, Basic Command Interpreter
Emulation ZPL II, DPL

 Brochure (PDF FILE)
