e-STUDIO5518A/6518A/7518A/8518A



The e-STUDIO5518A/6518A/7518A/8518A are high-end monochrome MFPs that boast printing output 55/65/75/85 ppm. This series features enhanced user interface, advanced cloud and mobile printing capabilities. Those functions enable those of you who need to copy and scan large amounts of monochrome documents with high speed and high volumes. Such advanced functions will help you improve your daily work.

Specifications

Model e-STUDIO5518A e-STUDIO6518A e-STUDIO7518A e-STUDIO8518AC
General Feature
Copy / Print Speed (ppm) 55 65 75 85
Warm-up Time Approx. 24 sec. Approx. 20 sec.
Memory 4 GB
Storage 320GB Self-Encryption HDD
Dimension (W × D × H) 955 × 698* × 1,227 mm / 37.6" × 27.5"* × 47.7"
Weight Approx. 195 kg / 430 lb
Input Paper Capacity Standard 3,520 sheets
Maximum LCF 6,020 sheets/ 4- Drawer model: 4,780 sheets
Available Paper Weight 60 - 300 g/m² / 16 lb. Bond - 110lb. Cover
Available Paper size 100 × 148 to 330 x 483mm / 100 × 148 to 13" x 19", Banner paper (1,200 mm)
Document feeder Standard 300-sheet DSDF
Duplexing Standard
Finishing Option Multi-Position stapling finisher,Saddle Stitching Finisher
Copier Feature
First Copy Speed 5.2 sec. 4.5 sec. 4.1 sec.
Resolution 2,400 × 600 dpi (with smoothing)
Multiple Copy Up to 9999
Printer Feature
Resolution 600 × 600 dpi, 2,400 × 600 dpi (with soothing), 1,200 × 1,200 (PS only), 3,600 × 600 dpi (with soothing/PS only)
PDL PCL6 Emulation, PS3 Emulation, XPS
Interface Standard USB (High speed), 10/100/1000BASE-T
Option Wireless LAN (IEEE802.11 b/g/n), Bluetooth
Scanner Feature
Resolution 100/150/200/300/400/600dpi
Scan Speed Up to 240 spm (Duplex) / Up to 120 spm (Simplex) (300 dpi)
Data format Standard TIFF, PDF, XPS, JPEG, Slim PDF, PDF/A
Option DOCX, EXLS, PPTX, Searchable PDF
Scan Protocol SMB, FTP, IPX/SPX, FTPS, USB, Netware
Scan features File, Email, USB, e-Filing Box, TWAIN, Local HDD, Share Point, iFax, Fax, WS Scan
Internet Fax ITU-T T.37 (Simple mode)
Fax Feature (option)
Communication mode / Modem Speed Super G3 / 33.6kbps - 2.4 kbps
Data Compression JBIG, MMR, MR, MH
Number of Lines (Std. / Max.) 1 / 2
Phonebook 3,000 stations
Security Feature
Standard Self-Encryption HDD, Private Print, Encrypted PDF, User Authentication, Role Based Access Control, IP/MAC address filtering, SNMPv3, SSL
Optional Data Overwrite, IPsec, FIPS certified Self-Encryption HDD

* Depth is different depending on angle of the control panel.
**Specifications, and availability of models and options vary by region.
