DB-EA4D wins covered international "iF product design award"

The compact, rugged and robust DB-EA4D double-sided label printer has been designed to offer a low-cost and green solution for applications requiring dual output.
With user-friendly operation and high-speed printing, this innovative technology provides a reliable and efficient alternative to traditional single-sided solutions.
The iF product design award offers an important platform to have one’s product’s design quality professionally validated by an international jury of experts.


Today’s labelling solutions create waste by the need to throw away the backing paper. In line with its ever more green endeavours Toshiba has addressed this issue by developing the DB-EA4D 2-sided direct thermal printer which adds value and usability to a label’s backing paper, or the back of a ticket, by printing directly onto it.


The solid design and small footprint ensures the printer has the flexibility to operate in any environment or application, from diverse transport and logistics industries requirements to confined retail and logistical operations.
The label and backing paper are printed simultaneously, facilitating fast output of labels and receipts with speeds up to 6ips.


Using parcel deliveries as an example, the address label for a delivery can be printed at the same time as the delivery’s packing list is printed on the label’s backing paper. Dual-sided printing offers various savings aside from the lower media costs, e.g. reducing storage space and shipping costs as fewer label or receipts are required.


The intuitive LCD backlit menu allows simple user operation, supported by colour LED notification lights (using colours distinguishable by the visually impaired). Auto-feed functionality enables trouble-free quick paper-loading, and easy maintenance is facilitated with tool-less replacement of key components like the printhead and platen roller.


The DB-EA4D is available with paper roll holder options, further enhancing the flexibility and range of applications for printing. With Bartender as standard and the option to download enhanced software, the user can easily design the label to meet the requirements of the business.


Printhead Flat Head
Dimensions 237(H) x 240(W) x 226(D) mm
9.3”(H) x 9.5”(W) x 8.9”(D)
(Not including Paper Roll Holder)
Interface USB / LAN / SNMP (Windows® driver)
Optional Interface Parallel - Standard on EU Model
Power AC 100 to 120V 50/60Hz or AC 220 to 240V 50Hz
100V - 240V 3.3A - 1.4A
Display 2 line LCD / 3 keys / 2 LED
Method Direct thermal
Print Width Maximum 104 mm (4.1”)
Print Length Maximum 547.8 mm (21.6”) both sides
Max. Print Speed 6 ips (152.4 mm/sec) speed is automatically adjusted
Resolution 203dpi (8 dot/mm)
Font / Barcode Windows®
Media Configuration Roll, Fanfold & Single Cut Sheet
Roll Diameter (max) 203.2 mm (8”)
Paper Width / Fanfold 58 to 130 mm (2.3” x 5.1”)
Paper Alignment Centre
Paper Roll Holder
